Capacity
Max turning diameter: 13.0 in
Max turning length: 20.1 in (optional long‑bed: 29.9 in)
Max swing: 23.6 in
Bar capacity: 2.63 in
Spindle
Speed: 4,500 RPM
Power: 20 HP
Spindle nose: A2‑6
Indexing: 0.001°Axes & Travels
X‑axis travel: 9.8 in
Y‑axis travel: 3.94 in (±1.97 in)
Z‑axis travel: 22.8 in (optional 32.6 in)
Rapid traverse (X/Y/Z): 790 ipm
Turret & Tooling
Stations: 12‑station heavy‑duty turret
Live tooling: Yes
Live tool motor: 5 HP, 6,000 RPM
C‑axis: Standard
Y‑axis: Standard
This equipment has been sold. Similar equipment available now is shown below.
