X Travel – 15.7
Y Travel – 13.8
Z Travel – 13.8
B axis – Tilting -50° ~ +110°
C axis – Rotary 360°
Max Table Load – 441 lbs
Spindle – 15,000 RPM
Tape – Big Plus / CAT40
Spindle Power – 10 HP
Number of Tools – 48
139x130x118 – 13,250 lbs
Control – Fanuc 31i-MB5
Oil/Air Lubricated Spindle, Spindle Chiller, Spindle Air Dryer, Spindle Motor Plate Cooling, and Thermal Compensation
Blum NT-Series Laser Tool Length Measurement System
Blum TC-60 Spindle Probe w/ Table Center Point Calibration Ball & Kinematic Software
Heidenhain Linear Scales in the X/Y/Z Axes, Heidenhain Rotary Scales in the B & C Axes
Robust Bridge Type Construction with 1.771” (45mm) Linear Roller Guide Ways in the X/Y-Axes
and 1.377” (35mm) Z-Axis
Full Circular Hydraulic Brake System for Rigid B & C Axis Clamping
Coolant System includes Spindle Coolant Nozzels (4), Spindle Coolant Ring Nozzels (4), Chip
Wash Down, and Coolant Gun
Spindle Air Blast Nozzles (2) and Air Gun
