Specifications
Power: 6000W
Laser Type: Fiber
Sheet Size: 5′ x 10′
Max Positioning Speed X/Y: 3937 IPM
Max Simultaneous Positioning Speed: 5511 IPM
Bilateral Repeatability of Positioning of One Axis R (Following ISO 230-2:2014(E)): ±0.002 in
Bilateral Repeatability of Positioning of One Axis M (Following ISO 230-2:2014(E)): ±0.004 in
Edge Detection Accuracy: ±0.019
Max Weight of Workpiece: 1,984 Lbs
Table Changeover Time: 24 s
Polarization: Unpolarized
Wavelength: 1 µm
Pulse Frequency: 1 – 2500HZ
Maximum Sheet Thicknesses: Steel: 0.750 in
Maximum Sheet Thicknesses: Stainless Steel: 0.750 in
Maximum Sheet Thicknesses: Aluminum: 0.750 in
Maximum Sheet Thicknesses: Brass: 0.375 in
Maximum Sheet Thicknesses: Copper: 0.375 in
Total Electrical Consumption of System: 29kW
MFMC 6000W Pro Series Power Source, Hasch Coolant System,Shuttle Table, Windows Based Controller
Additional Info
Approx 120 Hrs Cut Time, Service and support through Bystronic.
This equipment has been sold. Similar equipment available now is shown below.
