HOLZ-HER Dynestic 7532 | Nesting Machining Centers

The DYNESTIC 7532 Gantry CNC Machine expands the limits for
nesting technology to new dimensions. Solid machine construction
and technology at the highest level ensure high production capacity
and precisely produced work.
■■ Welded moving stands in gantry design – high rigidity, particularly
stable for maximum loads.
■■ Two synchronized servo-drives in X direction.
■■ Covered, ground and hardened v-guides on all axes for exceptional
precision and long service life.
■■ High dynamics and a vector speed of 100 m/min.
■■ High flow nesting table for optimum vacuum distribution.
■■ Selection of high power, precision milling spindles with 8 kW or
12 kW air cooled or 10 kW liquid cooled.X Travel-3700MM / Y- Travel 2200mm Vector Speed 100m/Min, 10-24,000 RPM, 15 Spindles , 14 Position Tool Changer, High Flow Nesting Table with Continuous Vacuum FielEffective and convenient programming with CAMPUS/
NC-Hops software package.
■■ I ntegrated GUI including aCADemy CAD module.
Also for professional DXF/DWG import to machine.
■■ HOLZ-HER BetterNest Software available for rectangular
and free-form nesting with intelligent cutting
optimization.
■■ The open software architecture allows a variety of
import possibilities for linkage to third party software
partners.
Campus/NC-Hops Campus/NC-Hops
BetterNest
Rectangular nesting Free-form nesting
CabinetControl
CabinetControl Base
Perfectd
