| Swing | 40.6" | 1,031.2 mm |
| Machining Length | 126" | 3,200.4 mm |
| # Axis | 2 | 2 |
| Chuck Size | 32" | 812.8 mm |
| Bar Capacity | 14.37" | 365 mm |
| Power | 60 hp | 44.7 kW |
| Max RPM | 300 RPM | 300 RPM |
| Turning Dia | 35.43" | 899.92 mm |
| Tailstock | Yes | Yes |
| Live Tooling | No | No |
Fanuc 0i-TD CNC Control
Tool presetting system (tool presetter)
Lubrication system
Rigid tapping on main spindle
Profluid Oil Cooler (Spindle Chiller)
145 PSI Coolant Pump
Programmable Tailstock (MT #6)
Chip Conveyor - Side Discharge
CHUCKS
(2) 4 Jaw, 32" Diameter, A2-20, Forged Steel, Extra Heavy Duty, Oil County, Manual Independent Lathe Chuck, 14.75” Through Hole
STEADYREST
RIP-225 - "Pass Thru" Manual Steady Rest (6.1" - 25" Capacity)
