24” WEST MICHIGAN MODEL 24 SPLINE ROLLER, NEW 2018
ConditionUsed
1 available
"Fantastic deal on a 2018 WEST MICHIGAN Model 24 Spline Roller! Silverlight CNC, Inc is selling this reliable used equipment, featuring a 24" rack size, 1.5" OD, and maximum rack box depth of 5.0". With under arm support, one-piece welded construction, and no induced taper, this machine is perfect for cold forming splines and threads. Comes with a coolant system and a hydraulic tank reservoir of 50 gallons. Overall dimensions: 120" x 72" x 161" tall. Trust Silverlight CNC, Inc for quality used equipment. Contact us today!"
Catalog Features and Specifications:
…Rack Size: 24”
…OD: 1.5”
…Max Rack Box Depth: 5.0”
…Opening: 5.5”
…Under Arm Support with Tailstock
…One-Piece Welded Construction
…No Shimming Required for Straightness
…Runs Various Lengths w/ No Induced Taper
…Cold Form Splines and Threads w/o Tie Bars
…Coolant System
…Hydraulic Tank Reservoir: 50 Gallons
Overall Machine Dimensions (approx.): 120” x 72” x 161” Tall
System Weights (approximate):
…Machine Weight: 25,000 lbs.
…Hydraulic Tank & Stand Weight: 5,700 lbs.
